在当下工业生产注重高效与空间利用的时代，伸缩式喷漆房的出现满足了大型工件喷漆作业的需求，许多企业在处理大型工件喷涂时需要灵活调整作业空间，这时伸缩式喷漆房的优势便充分展现出来。不过设备使用一段时间后，总要进行一些必要的检查。接下来就为大家介绍伸缩式喷漆房的检查方式。

　　In the current era where industrial production emphasizes efficiency and space utilization, the emergence of telescopic spray painting rooms has met the needs of large-scale workpiece spray painting operations. Many enterprises need to flexibly adjust the working space when handling large-scale workpiece spray painting, and the advantages of telescopic spray painting rooms are fully demonstrated at this time. However, after using the device for a period of time, it is necessary to conduct some necessary checks. Next, we will introduce the inspection method of the telescopic paint booth.

　　开机检查：

　　Power on inspection:

　　伸缩式喷漆房启动后，要检查框架传动系统的运行状态，运行时的噪音应较小，且没有异常声响。驱动电机及传动部件运行要稳定可靠，温度应≤环境温度 + 70℃。各连接部位的润滑情况应良好，若润滑不足需及时补充。轨道与滑轮配合应顺畅无卡顿。

　　After the retractable paint booth is started, the operation status of the frame transmission system should be checked. The noise during operation should be low and there should be no abnormal noise. The operation of the drive motor and transmission components should be stable and reliable, and the temperature should be ≤ ambient temperature+70 ℃. The lubrication of each connecting part should be good, and if the lubrication is insufficient, it should be replenished in a timely manner. The coordination between the track and pulley should be smooth and without any jamming.

　　停机检修：

　　Shutdown maintenance:

　　打开检修口检查各传动部件的润滑状况与磨损程度，润滑油应没有杂质、不发生变质。若存在杂质需及时更换，润滑部位的油量控制在合理范围。检查两侧驱动装置的同步性，确保运行时不会出现卡顿或偏移，传动链条或皮带应无断裂、保持完好。检查轨道是否存在变形或异物，确保无严重磨损。查看阻燃 PVC 布的密封情况，确保无破损漏风。检查防爆照明灯的线路连接是否牢固。查看房体框架有无破损和变形。检查安全限位装置是否灵敏有效。

　　Open the inspection port to check the lubrication condition and wear level of each transmission component. The lubricating oil should be free of impurities and not have deteriorated. If there are impurities, they need to be replaced in a timely manner, and the amount of oil in the lubrication area should be controlled within a reasonable range. Check the synchronization of the driving devices on both sides to ensure that there is no jamming or deviation during operation, and that the transmission chain or belt is intact and undamaged. Check for any deformation or foreign objects on the track to ensure there is no severe wear. Check the sealing condition of the flame-retardant PVC cloth to ensure no damage or air leakage. Check if the wiring connection of the explosion-proof lighting is secure. Check if the frame of the house is damaged or deformed. Check if the safety limit device is sensitive and effective.

　　关键部件细致检修：

　　Detailed maintenance of key components:

　　拆下驱动电机的固定螺栓，将电机与传动机构分离开来。拆下轨道固定件，清理轨道内的杂物。用专用工具检查传动齿轮或链轮的啮合情况，必要时进行调整。检查阻燃 PVC 布与框架的连接部位，更换老化或破损的连接件。拆卸过滤装置的固定部件，取出过滤材料进行清洁或更换。检查风机及风道的运行状况，清理内部积尘。用清洁剂擦拭房体内壁，检查密封胶条的完好性。

　　Remove the fixing bolts of the drive motor and separate the motor from the transmission mechanism. Remove the track fasteners and clean the debris inside the track. Use specialized tools to check the meshing of transmission gears or sprockets, and adjust them if necessary. Check the connection between the flame-retardant PVC cloth and the frame, and replace any aging or damaged connectors. Disassemble the fixed components of the filtering device, remove the filtering material for cleaning or replacement. Check the operation status of the fan and air duct, and clean the internal dust accumulation. Wipe the inner wall of the room with a cleaning agent and check the integrity of the sealing strip.

　　伸缩式喷漆房凭借适应性强、空间利用率高、成本合理等优势，被广泛应用于汽车制造、重型机械、船舶修造、大型设备生产、五金加工等多个行业领域。

　　Due to its strong adaptability, high space utilization, and reasonable cost, the retractable spray painting booth is widely used in various industries such as automobile manufacturing, heavy machinery, shipbuilding, large-scale equipment production, and hardware processing.
